The EC5AP impulse driver will control your Favag, Westerstrands, BBC and similar Slave Clock

EC5AP - Alternating Polarity Slave Clock Impulse Driver

A small circuit controlled by a crystal and micro-controller and giving either a 0.5 second, 1 second, 30 second or 60 second pulse to drive a slave clock in the absence of a Master Clock. Small enough to fit behind or in the clock.

The controller supplies a pulse at the correct interval to run the clock. The clock can then be powered by a battery pack located in the back of the clock or by an external wired power supply if desired. For 0.5 second and 1 second pulsing a plug in PSU is recommended. It will come as a mounted circuit or enclosed for protection of components and ease of fixing.

This driver produces a 24V output pulse using a 12v battery or PSU

Features..

∆ 0.5, 1, 30 or 60 second pulse of alternating polarity

∆ External buttons to Pulse forward and hold to stop pulsing

∆ LED indicators

∆ 1 hour DST Forward

∆ 1 hour DST Back

∆ Better than 0.4 sec per day accuracy

Comes with a plastic backing/mounting plate or full enclosure

Mounting plate Dimensions: 110 x 58mm (60mm inc buttons) 25mm high

Uses the same power supply to drive the clock and the driver

Power connection is via a 2.1mm pin plug



All parts, Driver board, and Battery packs come with
double sided tape for easy fixing.

APclockrear
My Gents/GEC
and4pack
4 + 4 C cell
EC4PSUw
regulator
APclockfront1
whitecable
Euro12vPSU
ADD TO CART
UK Plug in  12v
extnlead3m
ADD TO CART
EC5APEnc
EC5APMntd
resistivelead
GentsAPmech
Resistive Lead
ADD TO CART
50Hz to 60Hz
Version on  mounting plate
Fully enclosed version 65

Contact me... products@electric-clocks.co.uk

UKflag
ADD TO CART
ADD TO CART
item1b1a3a1a
plug
socket
ADD TO CART

P&P - will be added at checkout
Example: driver and battery holders posted to UK P&P is 6

ADD TO CART
